N DESCRIPCION DESCRIPTION 250 / 280 / 300 Cant.
1 CHASIS TRIAL TRIAL FRAME BT10000GG-CBN-1 1
2 PLACA PROTECCIÓN MOTOR TRIAL ENGINE PROTECTOR PLATE BT10000013012 1
3 TUERCA NUT 956 RAPIDA M6 M6 CHIMNEY NUT T2606000 8
4 ULS 8X20 8X20 ULS T0508020 4
5 ALLEN M10X140 ZINCADO 12.9 M10X140 ALLEN SCREW T0310140 1
6 TUERCA ESPECIAL M10 SPECIAL M10 NUT BT280210069 1
7 ALLEN 10x85 10X85 ALLEN SCREW T0301085 1
8 TUERCA AUTOBLOCANTE M10 BAJA SPECIAL M10 NUT T2110001 1
9 GRAPA FIJA TAPA LATERAL SPECIAL NUT TO FIX SIDE COVER BX250020029 2
10 CTO. ESTRIBOS TXT RACING FOOTPEGS KIT BT140003013CT 1
11 TORNILLO ULS M8x30 M8x30 ULS SCREW T0608030 2
12 DISTANCIADOR SPACER BT27910006 2
13 MUELLES ESTRIBERA IZQUIERDA LEFT FOOTPEG SPRING M100004 1
14 MUELLE ESTRIBERA DERECHA RIGHT FOOTPEG SPRING M100003 1
15 TUERCA AUTOBLOCANTE M8 DIN985 M8 SELF-LOCKING NUT DIN985 T2108001 2
16 CASQUILLO PROTECTOR CÁRTER CRANKCASE BUSH PROTECTOR BT280310883 2
17 TORNILLO ALLEN CONICO M8X16 ALLEN TAPERED SCREW M8X16 T0408016 2
18 TORNILLO ULS 6X25 ULS 6X25 SCREW T0506025 1
19 PROTECTOR CADENA A CHASIS CHAIN PROTECTOR BT280212026 1
20 TUERCA AUTOBLOCANTE DIN-6926 M6 CON ARANDELA ZN M6 SELF-LOCKING NUT WITH WASHER T2206002 1
21 TIRANTE CILINDRO BRACE CYLINDER BT280110050 1
22 TUERCA AUTOBLOCANTE M-8 ALTA SELF-LOCKING NUT M8 HIGH T2108002 2
23 JUNTA TORICA PIPA O-RING STEERING COLUMN BT100503013 1
24 GOMA PROTECTOR TRASERO MOTOR REAR ENGINE PROT. RUBBER BT280336029 1
25 GOMA PROTECTOR DELANTERO MOTOR FRONT ENGINE PROT. RUBBER BT280236030 1
26 SOPORTE CDI CDI SUPPORT BT10001GG-CBN-1 1
27 TORNILLO ALLEN M6X20 M6X20 ALLEN SCREW T0306020 2
28 CINTA DE CIERRE ADHESIVA LOCKING ADHESIVE TAPE BT51120GG-CBN-1 1
29 CONJUNTO SOPORTE CDI CDI SUPPORT SET BT10001CT-CBN-1 1
30 CASQUILLO FIJA PROTECTOR CHASIS-CADENA BUSH FRAME-CHAIN GUARD BC250014050 1
Chasis 3
