N DESCRIPCION DESCRIPTION 250 / 280 / 300 Cant.
1 ALLEN 10X63 10X63 ALLEN SCREW BT35000013011 1
2 AMORTIGUADOR TRIAL REAR SHOCK ABSORBER BT300023013 1
3 TORNILLO ESPECIAL SPECIAL SCREW T0310046 1
4 GUIA PINZA DE FRENO REAR CALIPER GUIDE BT280222049 1
5 TORNILLO EJE BASCULANTE TRIAL SWING-ARM AXLE SCREW BT280212009 1
6 RETÉN 20-26-4 870 N BASCULANTE 20-26-4 OIL SEAL C220001 4
7 COJINETE BEARING BT280212032 4
8 CABALLETE TRIAL 99 SIDE STAND BRACKET BT280712010 1
9 CASQUILLO GUÍA EJE BASCULANTE SWING-ARM AXLE BUSHING BT280212108 1
10 EJE BASCULANTE TRIAL SWING-ARM AXLE BT44500R3009 1
11 BASCULANTE TRIAL TRIAL SWING-ARM BT40000CT-CBN-1 1
12 CUBRECADENAS CHAIN COVER BT42040RA3011 1
13 PROTECTOR PIÓN TRIAL 2002 PINION PROTECTOR BT280236021 1
14 PATÍN CADENA CHAIN GUIDE BT280412015 1
15 ULS 5X12 5X12 ULS T0505012 4
16 REMACHE CABOTA GRANDE 14X4 8X21 PATÍN RIVET T4505016 2
17 PROTECTOR CORONA TRIAL 2003 SPROCKET PROTECTOR BT57350RA3011 1
18 TORNILLO ROSCA-CHAPA 4.2X12 4,2X12 SCREW T259349 2
19 TUERCA AUTOBLOCANTE SELF-LOCKING NUT T2110001 1
20 ARANDELA REGLAJE 10.5X26X0.5 10.5X26X0.5 WASHER T4001026 4
21 CASQUILLO SUSPENSIÓN DIAM. 10 SUSPENSION BUSHING BT27712005 2
22 RETÉN 15X21X2 / 15X21X2 OIL SEAL 15X21X2 OIL SEAL C230001 8
23 COJINETE AGUJAS 15BM2116 NEEDLE BEARING BT27714009 6
24 TOPE AMORTIGUADOR SHOCK ABSORVER END OF TRAVEL BT311003013 1
25 TORNILLO ESPECIAL BIELETA 8X38 8X38 SPECIAL SCREW T0118038 2
26 CASQUILLO DISTANCIADOR BALANCÍN ARTICULATION SPACER BUSHING BT27914016 1
27 TUERCA AUTOBLOCANTE M8 ALTA SELF-LOCKING NUT T2108002 2
28 CASQUILLO BALANCÍN 99 ARTICULATION BUSHING BT27914014 2
29 CTO. TENSOR CADENA CHAIN TENSIONER ASSY. BT42000RCT3009 1
30 GOMA TENSOR CADENA TENSIONER CHAIN RUBBER BT42010RA3010 1
31 CASQUILLO TENSOR CADENA CHAIN TENSIONER BUSHING B560000 1
32 MUELLE TENSOR CADENA CHAIN TENSIONER SPRING M122000 1
33 ALLEN CONICO 8X30 TENSOR CADENA 8X30 CONIC ALLEN T0408030 1
Chasis 4
